Thread gauge, commonly known as screw gauge is a device used to measure the trail or the lead part of a thread or a screw head. Used extensively in metal manufacturing industries, thread gauges are an invincible tool to inspect and measure the proportions of components of tapped holes, nuts and bolts. They are often treated as a source for first-hand assurance in mechanical industries about the structure of tools and apparatus and detect if there are any faults in the design.
Thread gauges and its constituent kinds are mainly used to assert correctness of a product according to thread alignment. Size of thread gauges is defined by their thread diameter and pitch adhering to which their utilisation tends to differ. These thread gauges of varied sizes also come in different types which are further used for several purposes.
Types of thread gauges
- Go/NOGO –
These types of gauges are used to ensure whether the external threads are coherent with the inner threads of tools mainly of nuts and tapped holes.
- Thread Plug Gauges –
This type of thread gauge is used to check the internally threaded products.
- Thread Ring Gauges –
This is a significant type of thread gauge that finds its primary usage in checking the precision of the threads present in a tool.
- Setting Master Gauges –
This type of thread gauge is used to manufacture thread ring gauge.
- Plug Gauge styles –
A type of thread gauge differentiated by the threads designed in the handle of the gauge.
All the types as mentioned above of thread gauges have separate usage in the metal industry. Not to mention, all these sorts are used for the higher purpose of determining the precision of components.
Applications of different types thread gauges
Thread gauges are instrumental in asserting the pitch of a tool that is mostly found in screws and tapped hole. Besides that, thread gauge has been used for several other purposes in metal processing and metalworking industry. Some of them are mentioned below:
- Used for determining whether the threads present on the outer part of the tools are aligned with the threads present in the internal region.
- It is used for asserting the tolerance of the tool.
- It is used to measure the accuracy and the precision of male gauge.
- Check the accuracy of both plastic as well as metal screws.
- Determine the disparity in the designs and the threads of the components.
- They are used for certifying a thread ring page.
Furthermore, thread ring gauges which form a constituent type of thread gauge is used to check the accuracy of the externally threaded structure. These gauges are moreover used to determine the tolerance of the metal component be it a bolt when it passes and correctly fits in the GO ring and NO GO ring. In addition to the fact, the design and the structure of these gauges are susceptible to change due to exposure.
